Test Program
Bowie & Dick Test Helix Test Vacuum Test
Safety Features
Safe Valve Double Control Lock and Self Test Alarm System
Sterilising Data
Print by Optional External Mini Printer or Download From USB Port
Capacity of Water Tank
Two Water Tanks Inside
3.5L Clean Water Tank
5L Waste Water Tank
3.5L Clean Water Tank
5L Waste Water Tank
Sensor Specifications
| Capacity | 23L |
| Sterilising Temperature | 121 C,134 C |
| Dry Procedure | Vacuum drying |
| Display | 128X64 Dots LCD screen, multi-language |
| Data Showing | Pressure: ±0.01bar, Temperature: 0.1°C |
| Voltage | 220V±10%/50Hz |
| Power | 2100W |
| Chamber Size | 250X450mm |
| N.W./G.W | 48/52KG |
| Overall Size | 660X550X560mm |
*All specifications and images are indicative and subject to changes
